Platinum Plus
17
Standard Mode Programming Guide
Where do I start?
Start with the Install Menu. Later programming steps can depend on
earlier steps. You can use this chart as a guide.
Standard Mode Programming Steps
Step 1 … 6. Install Menu Comments:
6.1
Install | Setup
Ventilation Mode ► Standard
Language ► English
Temperature Unit ► ºF
Static Pressure Unit ► Inches water
column
Fan Air Capacity Unit►CFM
Length Unit ►Feet
Baud Rate ► 9600
House Number, enter as required
Growing Zones, enter as required
Minimum Vent ► usually Yes
Natural Vent ► usually No
Tunnel Vent ► usually Yes
History Resolution ►for history view,
1 minute to 1 day
1. ‘Growing zones’ is the
number of sensor setups
including full house.
2. Minimum Vent includes
power ventilation through
transitional, but not natural
or tunnel.
3. History resolution applies
to History View in the
History Menu.
6.2
Install | Relay
Layout
Program the installed relays as the
electrician wired them.
1. Move the cursor to the relay to be
programmed.
2. Press ‘Enter’ to bring up the list of
relay types.
3. You can use the up/down arrow
keys to scroll through the list.
4. To move quickly to a relay type,
use the two digit code for the relay
type.
5. For relay types past code 99, press
the +/- key first, then the last two
digits.
6. Mark required ventilation modes
for each relay with check marks
1. Radiant Heat Low and
Heat relays operate
identically. However,
radiant low can have
associated high level and
ignition outputs.
2. AC/DC operation mode:
the AC mode keeps relays
on at half power instead of
full power to reduce heat
production.
3. Under Help | Set
Parameters, you can select
5 relays to operate in
reverse.
4. To move a single use relay
code such as heat from one
relay to another, delete the
