Platinum Plus
27
Control Menu
The Control Menu is the place to enter actual operating settings for your poultry house. The
first two menus in the control category are TEMP & TIMER SETTINGS and
TEMPERATURE & HUMIDITY.
Temperature and Timer Settings
The TEMP & TIMER SETTINGS menu sets the ON and OFF temperatures for each device,
and also selects the timers that apply to particular devices. The on and off temperatures
normally move with the SET temperature, although you can turn the temperature curve off
under CONTROL MODE. To simplify entering device on and off temperatures, you might
want to make the set temperature some even number, such as 80.0ºF. That way, you simplify
entering tenths of a degree. Following are example TEMP & TIMER SETTINGS based on a
Set Temperature of 75.0ºF.
Temperature and Timer Settings
Stage/Device
On
Temperature
Off
Temperature
Timer
Cool # 2 91 89
Cool # 1 90 89 Timer 1
Tunnel Fan 8 89 88
Tunnel Fan 7 88 87
Tunnel Fan 6 87 86
Tunnel Fan 5 86 85
TUNNEL SETTING 86 83
Tunnel Fan 4 85 84
Tunnel Fan 3 83 82
Tunnel Fan 2 82 81
Tunnel Fan 1 81 80
Exhaust Fan 2 79 78
Exhaust Fan 5 79 78
Exhaust Fan 3 78 77
Exhaust Fan 1 77 76 Min Vent
Exhaust Fan 4 77 76 Min Vent
SET TEMPERATURE 75.0
Heat 1 73 74
Heat 2 73 74
Heat 3 73 74
Heat 4 73 74
Heat 5 73 74
Help | Set Parameters
Minimum Tunnel Fans 3 Tunnel Exit Delay 1
Non Brood Area Diff. Below Heat Stir Fan Minimum Vent Offset, +/- Sec
Stir Fan Operate Duration (Sec) Stir Fan Set Function (Stop/Cont)
Radiant Heater High Differential Radiant Ignition Time, Seconds
Note the ‘Set’ Parameters at the bottom of the Temperature & Timer Settings table. You can
find them either in the System Parameters under Install, or you can push Help while in
Temperature & Timer Settings, and choose the Set option. Generally, this is shown as Control
| Temperature &Timer Settings | Help | Set.
