Platinum Plus
81
7. To delete a line, simply set the day to 0.
When you exit the menu, that line will
delete and subsequent lines move up.
8. To add a new line in the middle of a table,
simply add it at the end. When you exit the
menu, it will sort into its correct spot.
Help | Set Parameters
1. Temperature Band
: the on/off differential
or Happy Zone with respect to temperature.
2. Humidity Band
: the on/off differential or
Happy Zone with respect to humidity.
3. Flush Cool Pad At
: time setting in 24 hour
format at which to begin cool cell flush.
This provides a means to wash contaminants
out of the cool cells periodically.
4. Cool Pad Flush Duration (minutes)
:
length of time in minutes for which the flush
is to continue.
5. Precision Mode Only
: Minimum Level to
Enable Operation: the cool pad #
and cool #
will not operate at ventilation levels below
this minimum, even if other conditions are
satisfied.
Foggers, Precision Mode
The Fogger settings provide 20 lines to program
inside the house foggers, similar to the Cool Pad
menu. The primary difference is that the
differential temperatures are relative to Target
rather than to Tunnel, and there is no flush
capability. However, there is a maximum
ventilation level parameter not available in the
Cool Pad menu.
1. Program applicable growth days in column
1. You can set several lines for a particular
growth day. They will sort into growth day
order when you exit the menu. Higher
growth days will supersede earlier growth
day settings when the growth day arrives.
The settings then apply until the next growth
day setting, so you need not set each growth
day.
2. Set the start time that applies to a particular
line, and the end time in their columns. The
time is in Military or 24 Hour format, so
afternoon times will have the hours equal to
13 or greater.
3. Enter the relative differential temperature
from your Target setting in Temperature
Curve. It is possible to enter a negative
differential by pressing the +/- key after
entering the number of degrees under
Tunnel Differential.
4. Enter the To Humidity setting. This is the
maximum humidity at which that line will
apply.
5. Enter On seconds. The Cool outputs will not
operate at all if there is nothing in the On
setting, so it is mandatory to change it to a value
other than 0.
6. Enter the Off seconds if you wish to have the
cool system cycle on and off. This is optional
according to your needs.
7. To delete a line, simply set the day to 0. When
you exit the menu, that line will delete and
subsequent lines move up.
8. To add a new line in the middle of a table,
simply add it at the end. When you exit the
menu, it will sort into its correct spot.
Help | Set Parameters
1. Temperature Band
: the on/off differential or
Happy Zone with respect to temperature.
2. Humidity Band
: the on/off differential or
Happy Zone with respect to humidity.
3. Minimum Level to Enable Operation
: the
foggers will not operate below this minimum
ventilation level.
4. Maximum Level to Enable Operation
: the
foggers will not operate at ventilation levels
higher than this maximum level.
Stir Fan, Precision Mode
Select one of five available programs, labeled A
through E by applying check marks using the +/-
key for each stir fan. Programs currently ON are
marked by a dark box at the bottom of this screen.
Set the program parameters by selecting Help | Set:
1. Program A (for minimum ventilation): this
program is primarily intended to assist with
minimum ventilation by turning on the stir fans
with a specific relation to the cycle timers set in
the ventilation table.
a. Operate After End Of Cycle
: select whether
the delay to start Program A stir fans is
measured from the ON edge of the ventilation
table cycle timer, or from the OFF edge. The
cycle timer of the current ventilation level is
the reference.
b. Delay for Operation
: set the delay in
seconds from the chosen edge. To make the
delay negative, press the +/- key after
entering the seconds.
c. Time for Operation
: set the program A
operation time in seconds.
d. From Level
: minimum level to operate
program A.
e. To Level
: maximum level to operate program
A.
f. From Time
: earliest time to allow stir fan
operation by program A (24 hour or military
time format applies).
