Platinum Plus
51
Humidity
Humidity treatment forces an
increase in ventilation level for a
minimum duration after an interval, if
humidity is higher than set. It does not
force a change in ventilation style from
side or cross ventilation to tunnel
ventilation.
Cooling Pad
Cooling Pad
Day Start Time End Time Tunnel
Diff
To % RH On Sec Off Sec
21 10:00 18:00 4.0 75 30 570
21 10:00 18:00 6.0 75 100 500
Help | Set Parameters
Temperature Band Humidity Band (%)
Flush Cool Pad at: Cool Pad Flush Duration:
Minimum Ventilation Level to Enable Operation: 22
The cooling table provides a sophisticated table to set up your cool pads. You can set
different amounts of water by bird age, differential temperature and humidity.
Humidity Treatment
Day
Humidity Interval
Minutes
Duration
Seconds
1 70 5 30
1 80 5 100
Help | Set Parameters
Humidity Band (%) 2%
Humidity Treatment Below Heat? 0 (No)
To Next Page
