Platinum Plus
25
Analog Sensors
The Platinum Plus regards temperature and
humidity sensors as ‘analog sensors’. These
sensors measure a continuous range rather than just
on or off. By default, it comes with 6 sensors which
are connected in order.
Digital Sensors
Next are the digital sensors. These allow you to
monitor water consumption and feed consumption if
your building is equipped. The Overtime inputs allow
alarming and shutting down your feed system in the
event of bridged feed, an empty tank, or other feed
problem. You can use auxiliary digital inputs for water
pressure and other alarms.
Curtain Setup
Curtain Setup tells the Platinum Plus
how fast your curtains and side inlets move.
It needs this information to properly
calculate automatic inlet advance as well as
inlet and curtain positions. Enter opening
and closing time in seconds for the tunnel
inlet curtain in the Tunnel row, and for the
side vents in the Inlet row.
Analog Sensors
Channel Sensor
1 Temperature Sensor 1
2 Temperature Sensor 2
3 Temperature Sensor 3
4 Temperature Sensor 4
5 Temperature Sensor 5
6 Temperature Sensor 6
7
8
9 Hum.Sensor In
10
11
Digital Sensors
Channel Function
1 Water Meter
2 Feeder-1 Overtime
3
4 Feed Count
5
6 Feeder-2 Overtime
7
8 Feed Count
Curtain Setup
Curtain Open Close
1
2
3
4
Tunnel 250 250
Inlet 35 35
