Rotem Platinum PLUS - Page 24

Poultry House Control
24
Relay Assignments
Mode Checks
Relay Function Min Nat Tun
1 01 Heat 1 √
2 02 Heat 2 √
3 03 Heat 3 √
4 04 Heat 4 √
5 05 Heat 5 √
6 53 Exhaust Fan 1 √
7 55 Exhaust Fan 2 √
8 57 Exhaust Fan 3 √
9 54 Exhaust Fan 4 √
10 56 Exhaust Fan 5 √
11 33 Tunnel Fan 1 √ √
12 34 Tunnel Fan 2 √ √
13 35 Tunnel Fan 3 √ √
14 36 Tunnel Fan 4 √
15 37 Tunnel Fan 5 √
16 38 Tunnel Fan 6 √
17 39 Tunnel Fan 7 √
18 40 Tunnel Fan 8 √
19 41 Tunnel Fan 9 √
20 98 VFS (Fail Safe), Extra System 1 √ √ √
21 104 Side Inlets Open √
22 105 Side Inlets Close √
23 102 Tunnel Inlet Curtain Open √
24 103 Tunnel Inlet Curtain Close √
25 108 Cross Fill Auger 1 √ √ √
26 109 Cross Fill Auger 2 √ √ √
27 78 Cool Cell Pump 1 √
28 79 Cool Cell Pump 2 √
29 107 Lights √ √ √
30 107 Lights √ √ √
31
32
33
34
35
36
37
38
39
40
Note: Under Help | Set you can reverse up to 5 relays, and
select normal or power saving operation modes. By default,
the Platinum Plus uses power saving mode for the relays to
reduce heat inside the controller.
