Installation drawings
Positioning of the frame components – All hinge sides
Turn-Only / Tilt&Turn – Basic security
without
centre post
Striker dimensions (mm)
horizontal, bottom – Basic security
12
52
86.5
18
Centre of clearance
CLH1 CLH1
Centre lock, horizontal, bottom
SRW / mm CLH1
see parts lists
Basic security
652 CL 600
Multipart centre lock, horizontal, with/without turn-restrictor
SRW / mm CLH1
see parts lists
Basic security
652 CL 600
