4. Diagnostics
ROS® v3.11User Guide 97 RMC30
4.7. Transferring Files
The Files Transfer form is used to transfer files between the device and a PC. To transfer files
using this form, either a TFTP server must be installed and running on the PC, or a TELNET
connection must be established with the device so that XMODEM can be used to transfer files.
If a TFTP server is installed and running on the PC, press GET to transfer from the PC to the
device, or PUT to transfer from the device to the PC.
Available files include:
• main.bin (application software)
• boot.bin (boot software)
• config.csv (configuration file)
• syslog.txt (system log file)
If the transfer is not completed within 1 minute, an error will be reported.
Figure 4.10. Files Transfer Form
PC File
The path and name of the file on your local PC. Use the Browse button to locate the file.
Device File
The name of the file on the device.
TFTP Server IP Address
The IP address of a TFTP server. A TFTP server application must be installed on your
local PC.
