Saab R5 - RS232 Signal Cable Pinout; R5 Power Cable Pinout

R5 SOLID AIS System
INSTALLATION
7000 118-200, C2 Page 23
2
Out
ECDIS - TxA (-)
RS422
Brown
3
In
Sensor1 - RxB (+)
RS422
Green
4
In
Sensor1 - RxA (-)
RS422
Yellow
5
In
Sensor2 - RxB (+)
RS422
Grey
6
In
Sensor2 - RxA (-)
RS422
Pink
7
In
Long Range - RxB (+)
RS422
Blue
8
In
Long Range - RxA (-)
RS422
Red
9
-
Long Range - GND
RS422
Black
10
-
ECDIS - GND
RS422
Violet
11
In
ECDIS – RxB (+)
RS422
Grey / Pink
12
In
ECDIS – RxA (-)
RS422
Red / Blue
13
-
Sensor1 – GND
RS422
White / Green
14
-
Sensor2 – GND
RS422
Brown / Green
15
In
Sensor3 – RxB (+)
RS422
White / Yellow
16
In
Sensor3 – RxA (-)
RS422
Yellow / Brown
17
Out
Long Range – TxB (+)
RS422
White / Grey
18
Out
Long Range – TxA (-)
RS422
Grey / Brown
19
-
Alarm Relay – GND
-
White / Pink
20
Out
Alarm Relay – Out
-
Pink / Brown
21
-
GND
-
White / Blue
22
-
-
-
Brown / Blue
23
-
Sensor3 – GND
RS422
White / Red
24
-
Alarm Relay - VCC
-
Brown / Red
25
In/Out
CAN (+)
Differential
CAN bus
N/A
26
In/Out
CAN (-)
Differential
CAN bus
N/A
Table 8 – 26-pin High Density D-sub
3.7.5 RS232 Signal Cable
Pin
Signal Name
1
Not Connected
2
Tx (Transponder side)
3
Rx (Transponder side)
4
Not Connected
5
GND
6
Not Connected
7
Not Connected
8
Not Connected
9
Not Connected
Table 9 – 9-pin female D-sub
3.7.6 R5 Power Cable, 7000 118-077, A
Pin
Signal Name
Colour
1
24VDC positive
Red
2
GND
Black
