R5 SOLID AIS System
OPERATION
7000 118-200, C2 Page 38
Long Range Message
Controls the behavior of the R5 SOLID sound buzzer
when an LR interrogation message is received.
AIS Message
Controls the behavior of the R5 SOLID sound buzzer
when a SRM or binary text message is received.
Inland RTA
Controls the behavior of the R5 SOLID sound buzzer
when an Inland RTA (Recommended Time of Arrival)
message is received.
4.4.12 Main Menu  Config Display  Time
Parameter Name
Description
Time Zone
This parameter defines if the times that are displayed in
the R5 SOLID should be in UTC or LOC (local) time. If
local time is chosen, the offset from UTC must be
specified with the three parameters listed below.
Offset sign
The sign of the local time offset from UTC.
Hours
The local time hour offset from UTC.
Minutes
The local time minute offset from UTC.
4.4.13 Main Menu  Config  Interface  Language
Parameter Name
Description
Language
Changes the language in all the menus and views of
the R5 SOLID. The changes will take effect
immediately when pressing “Save”.
4.4.14 Main Menu  Config Interface  Port Rate
Parameter Name
Description
Baud Rate
Changes the baud rate (bits per second) for the
corresponding serial port.
Checksum
When set to “Required”, all messages that are input on
the corresponding serial port to the R5 SOLID must
have a valid checksum.
When set to “Disabled”, messages both with and
without checksum are accepted on the corresponding
serial port.
