DH4 Installation Guide
p. 6
DH4 Installation
DH4 Installation
Installation Best Practices
Before you begin, keep in mind that it is your responsibility to avoid damaging safety or electrical systems. If you are not
The following table outlines the physical and environmental requirements for installing a DH4 DVR:
VENTILATION Install the DVR away from any sort of heat outlet, heater, or AC blower. Do not operate the DVR
in a closed -in area, or restrict ventilation in any way. The DVR requires air circulation to maintain
optimum operation temperature and provide best performance. Do not expose the DVR to
moisture!
SURFACE Do not mount the DVR to a plastic panel or other surface that is subject to constant vibration.
ORIENTATION Mount the DVR in either a horizontal or vertical orientation, or hung right side up, but NOT
upside down.
CLEARANCE
removal of the security front cover and easy access to the hard drive and USB ports. Allow
power cables.
MOUNTING CABLES The radius for the mounting cables will be dictated by the cable cover. The rear-most surface
of the cable cover will be about 3 inches from the back of the DVR to allow camera cables to
bend over each other.
ETHERNET CABLES Avoid right angle bends in the Ethernet cables.
POWER CABLES Provide enough slack on the power cable to prevent any force from being exerted on the
WARNING
It is your responsibility to avoid damaging safety or electrical systems. Ensure you read and understand the DH4 DVR
Installation Requirements.
If you are not condent in your ability to perform the procedures in this tutorial, please contact Technical Support at
1.844.899.7366 or PTsupport@safeeet.net.
