Safran LRF 6019 User Manual

LRF 6019 Integrator Manual
914928_TML_LRF6019_en_Version C
Public: 04.2019
Confidential & Proprietary  Safran Vectronix AG – All rights reserved
Page: 33/70
5.4.1 Absolute maximum ratings
These are specifications for stress limits only. Functional operation of the device at these ratings or above
is not implied. Exposure to absolute maximum rating conditions for extended periods of time may affect
reliability and cause permanent damage to the device.
Parameter
Min
Max
Unit
PWR_IN *
-15
+15
V
5V_HI_PWR *
-5.5
+5.5
V
PWR_SAFE
-0.3
5.5
V
RS232/RS422
-15
15
V
RS232/RS422 Interface Select
-0.3
5
V
Operating temperature
-35
70
°C
Storage temperature
-40
85
°C
* Reverse polarity protection for negative voltages only, the range of negative voltages is not
operational.
5.5 Electrical characteristics
Typical values -> PWR_IN = 5V; T = 25°C (unless otherwise noted); Laboratory power source.
Max values -> PWR_IN and/or 5V_HI_PWR at 5V over all temperature range.
Parameter
conditions
Min
Typical
Max
Unit
Power consumption OFF state with PWR_SAFE
5V_HI_PWR = 5V
PWR_IN <= 10 V
PWR_IN > 10 V
40
40
300
300
10
µW
µW
mW
Power consumption Standby
Typical
65
150
mW
Power consumption normal operating
Typical
430
500
mW
Power consumption during a range measurement
Typical
2.5
3
W
Power consumption during pointing, LRF6019-LP
Typical
0.75
1
W
Power consumption during pointing, LRF6019-HP
Typical
1.1
1.4
W
Inrush current peaks during measurement *1)
Typical
2
3
A
Input capacitance on 5V_HI_PWR
Typical
200
350
µF
Input capacitance on PWR_IN
Typical
350
500
µF
PWR_SAFE rise time
Typical
1.5
ms
*1) See Warning on current peaks
