6.5.6 Operating mode selection >LM,Op,x*<CS><CR>
This command initiates a switch of the operating mode.
The parameter x can take the following values:
 x=0  “OFF Mode”.
 x=1  “Stand-by Mode”.
 x=2  “Normal operating Mode”
NOTICE
The “OFF Mode” shall only be used together with the “PWR_SAFE” signal (Hardware pin#9).
It requires the “low to high” and “high to low” transitions for the correct functioning.
Transitions allowed without the use of “PWR_SAFE” signal (Hardware pin#9):
 From “Normal operating Mode” to “Stand-by Mode” >LM,Op,1*E1<0D>
 From “Stand-by Mode” to “Normal operating Mode” >LM,Op,2*E2<0D>
Transitions allowed with the use of “PWR_SAFE” signal (Hardware pin#9):
 From “Normal operating Mode” to “OFF Mode” >LM,Op,0*E0<0D>
 From “Normal operating Mode” to “Stand-by Mode” >LM,Op,1*E1<0D>
 From “Stand-by Mode” to “Normal operating Mode” >LM,Op,2*E2<0D>
 From “OFF Mode” to “Normal operating Mode” any single character to the module.
Operating mode selection command and response
Command
Inputs
Description
>LM,Op,x*<CS><CR>
>LM,Op,0*EO<0D>
Set the LRF in the specified operation mode as follow:
 Parameter x=0  OFF mode.
 Parameter x=1  Stand-by mode.
 Parameter x=2  Normal operating mode.
Response
Outputs
Description
No response expected.
Table 8: Operating mode selection command
Example of an Operating mode selection command transaction:
Host  LRF Module
Command frame: >LM,Op,1*E1<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
