Safran LRF 6019 User Manual

LRF 6019 Integrator Manual
914928_TML_LRF6019_en_Version C
Public: 04.2019
Confidential & Proprietary  Safran Vectronix AG – All rights reserved
Page: 54/70
6.6.5 Get current range gate settings >LM,Ig,x*<CS><CR>
This command retrieves the current range gate settings.
The parameter x can only take the values:
 x=1  Retrieves the minimum range gate settings.
 x=2  Retrieves the maximum range gate settings.
Get current range gate settings command and response
Command
Inputs
Description
>LM,Ig,x*<CS><CR>
>LM,Ig,1*D2<0D>
Get current range gate settings.
Example with x=1, get minimum gate range.
Response
Outputs
Description
>LM,Ig,g*<CS><CR>
> LM,Ig,00000*91<0D>
Response of the LRF module with parameter x=1.
Example with range gate (g) being zero.
Table 18: Get current range gate settings command
Example of a get range gate (min) settings command transaction:
Host  LRF Module
Command frame: >LM,Ig,1*D2<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Response frame: >LM,Ig,00000*91<0D>
Prompt: <
