Safran LRF 6019 User Manual

LRF 6019 Integrator Manual
914928_TML_LRF6019_en_Version C
Public: 04.2019
Confidential & Proprietary  Safran Vectronix AG – All rights reserved
Page: 43/70
6.5.3 Laser continuous low power mode >LM,Tl,x*<CS><CR>
This commands initiates a continuous low power laser emission at a wavelength of 1550 nm (typical).
The module provides this functionality for alignment purposes only (no range is measured).
The possible inputs for parameter x:
 x=0  OFF state
 x=1  lowest power
 x=…
 x=6  highest power
All emission levels are Class 1 eye safe and presents no risks for SWIR cameras.
Laser continuous low power mode
Command
Inputs
Description
>LM,Tl,x*<CS><CR>
>LM,Tl,1*E2<0D>
>LM,Tl,0*E1<0D>
Low power continuous laser emission with parameter x power level.
Example with x=1 (lowest emitting power).
Example to switch off.
Response
Outputs
Description
--
No response expected.
Table 5: Laser continuous low power mode command
Example of a laser continuous low power mode command transaction:
Host  LRF Module
Command frame: >LM,Tl,1*E2<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
Alignment is performed by the operator. Afterwards, the emission shall be deactivated.
Host  LRF Module
Command frame: >LM,Tl,0*E1<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
