LRF 6019 Integrator Manual
914928_TML_LRF6019_en_Version C
Public: 04.2019
Confidential & Proprietary  Safran Vectronix AG – All rights reserved
Page: 35/70
5.6 Serial Interfaces
5.6.1 RS232
The RS232 interface uses system connector pin#19 (RS232-TX) and pin#21 (RS232-RX) with the following
parameters:
Parameter
Value
Baud rate
57600 Bd
Data bits
8
Start bit(s)
1
Parity
Even
Stop bit(s)
1
Signaling levels
RS232 Levels
Please see chapter 5.2 Pin descriptions for RS232/422 Interface selection with pin#18.
5.6.2 RS422
The RS422 interface uses system connector pin#17 (RS422-TX P), pin#19 (RS422-TX N), pin#21 (RS422-
RX P) and pin#23 (RS422-RX N) with the following parameters:
Parameter
Value
Baud rate
57600 Bd
Data bits
8
Start bit(s)
1
Parity
Even
Stop bit(s)
1
Signaling levels
RS422 Levels
Please refer to chapter 5.2 Pin descriptions for RS232/422 Interface selection with pin#18.
5.7 Ground Concept
The LRF System has to be connected to the mechanical ground of the host system via the three screws
and the supportive conducting area around the three screws. The LRF bench is conductive.
