I/Q Data is processed at ASIC (MCB028A) to generate Color Data and it is sent to PC
Part. Detailed descriptions are as follows.
FPGA which received I/Q Data sends it to ASIC (MCB028A) to detect the Color
component. However, the Color component contains the Wall Noise and it go through the
process of Rejection, Smooth Filter, Post filter, etc. after sent to FPGA. In this process,
the Color Data is created and relayed to DMA & RTC Part of BE Board.
