1 - 10 WS80A Service Manual
2D
Dial-button
Button: Starts 2D mode.
Dial: Adjusts the 2D gain.
M / x
Dial-button
Button: Starts or ends M mode.
Dial: Adjusts M gain. Also, turning this dial-button when in 3D
View rotates the image along the x-axis.
PD / y
Dial-button
Button: Starts or ends Power Doppler mode.
Dial: Adjusts the PD gain. Also, turning this dial-button, when in
3D View rotates the image along the y-axis.
PW / z
Dial-button
Button: Starts or ends PW Spectral Doppler mode.
Dial: Adjusts the PW gain. Also, turning this dial-button when in
3D View rotates the image along the z-axis.
C / Ref. Slice Dial-button
Button: Starts or ends Color Doppler mode.
Dial: Adjusts the C gain. Moves the reference slice horizontally in
3D View.
3D
Button
Starts or ends 3D mode.
4D
Button
Starts or ends 4D mode.
CW / TB
Dial-button
Button: Starts or ends CW Spectral Doppler mode.
Dial: Adjusts the CW gain. Adjusts top and bottom margins of
ROI in 3D View-MPR. TB is an abbreviation for “Top-Bottom”.
Angle / LR
Dial-button
Button: Adjusts the angle of the sample volume in Spectral
Doppler mode. It is also used to adjust the BodyMarker’s probe
cursor or indicator angle.
Dial:
Adjusts left and right margins of ROI in 3D View-MPR. LR is
an abbreviation for “Left-Right”.
Depth
Switch
Adjusts the scanning depth of the image.
Focus
Switch
Changes location and number of focus on the target location you
wish to study.
Zoom
Dial-button You can magnify an image.
Q Scan
Button
Press this button to turn the Quick Scan function on. The ‘Q
Scan’ mark will appear at the top of an image.
Freeze
Button
Pauses/resumes scanning.
Save
Button
Saves an image or a report displayed on the screen to the
database.
