3 - 16 WS80A Service Manual
Button Sound
Set this to On or Off using the trackball. When this is set to on, the buzzer sounds each
time a button or dial-button is used.
▌ Patient Information
Save Patient Page as First Images
Set this to On or Off by using the trackball. If it is On, the Patient Information Entry screen
will be saved when creating an ID.
▌ Zoom Box Setup
Zoom Box Reference Position
Select the position of the Zoom Box Reference. You may select either Image or Zoom
Box.
▌ Quick Preset
Quick Preset Setup
Press the button to display Quick Preset Setup screen. After selecting the Probe,
Application, and Preset connected to the port, press the + button to add them to Quick
Preset. Up to 4 sets can be saved. The Probe, Application, and Preset saved will be
shown on the touch screen in the diagnosis mode.
