3 - 18 WS80A Service Manual
NOTE
To configure the Store Clip button, go to Utility > Setup > User Defined Key >
User Key Setup.
▌ Combination Action
Freeze with
Select a function to automatically execute when the Freeze button on the control panel is
pressed. It can be set up for each preset using the combo button. Available options are
BodyMarker, Caliper, AutoCalc, Measure, Text, and None.
– D or M Modes Only: When ‘Freeze with’ is set to Measure, Measure Freeze Action will
function only in Doppler and M Modes.
End Exam with
– None: Tapping the End Exam button on the touch screen exits Exam Mode and
switches the screen to the B Mode Scan screen.
– Patient Window: Tapping the End Exam button on the touch screen switches the
screen to the Patient Information screen.
– Reset Preset: The established preset has been initialized.
▌ Multiple Mode
Simultaneous Mode
You can decide whether to enable Simultaneous Mode in Spectral Doppler Mode, using
the following three options:
– Off: Select this if you do not wish to use Simultaneous Mode.
– Allow B/PW: Select this if you do not wish to use Simultaneous Mode in 2D/C/PW
Modes, but do wish to use it in 2D/PW Mode.
– Allow B/C/PW: Select this if you wish to use Simultaneous Mode for both 2D/PW
Mode and for 2D/C/PW Modes.
Color Mode Position on Dual Live
Select the position of the Color Doppler Mode in Dual Live Mode.
– Left or Top: Color Doppler Mode is located in the left or upper part of the screen.
