Samwon Tech TEMP880S User Manual

SAMWONTECH
1st Edition of TEMP880S IM : Sep. 21. 2005 Page 25 / 101
○
12
High
Temperature
Room Operation
Lamp
Displays red lamp when a heat
shock tester is operating high
temperature part.
▶ Turns off when preheating.
○
13
Normal
Temperature
Room Operation
Lamp
Displays yellow lamp when a heat
shock tester is operating normal
temperature part.
○
14
Low
Temperature
Room Operation
Lamp
Displays blue lamp when a heat
shock tester is operating low
temperature part.
▶ Turns off when preheating.
Pattern Type
☞ There are two pattern types(Type-1,2) as for Elevator Type, and four pattern types(Type-
☞ 1,2,3,4) as for Damper Type. The pattern type can be set up in 2.10 PATTERN SETTING
.
☞ Refer to 2.10 PATTERN SETTING.
Type-1 Type-2 Type-3 Type-4
