1st Edition of TEMP880S IM : Sep. 21. 2005 Page 46 / 101
○
5
2.11 DISPLAY SET
▶ Screen that adjusts light and activation of auto tuning.
▶ Screen that shows error history.
Diagram 2-43. Display Set Diagram 2-44. Error Histroy
No. Instruction Contents Additional Explanation
○
1
Tuning
Button
Activate program preparation
screen, AT button of program
operation screen or hide them.
▶ Displays or hides tuning button in
▶ Diagram2-15, Diagram2-16.
○
2
Power Saving
Time
Sets time for back light automatic
turn off.
▶ Initially set 10 minutes for longing the
▶ back light life.
○
3
Light
Increasing
Button
Lightens screen.
○
4
Light
Decreasing
Button
Darkens screen.
▶ Screen light may change as a trait of
▶ STN LCD. For example, it looks darker in
▶ winter and lighter in summer. Adjust
▶ light using this button.
○
5
Error History
Button
Shifts to error history screen.
○
6
Error
Occurrence
Order
Displays error occurrence order.
▶ It can display up to five. Error after the
▶ fifth one is stored at the end, and the
▶ first one is deleted.
○
7
Error
Occurrence
Name
Displays error occurrence name.
○
8
Error
Occurrence
Time
Displays error occurrence time.
○
9
Error History
Delete
Delete all error history.
○
1
○
2
○
3
○
5
○
6
○
7
○
8
○
9
○
4
