4.4 Explanation of D-REGISTER
D-Register is a group of gathering all the data which is provided to check all the condition of TEMP880S.
D-Register is grouped by each 100 unit, basically, depending on the contents and the contents are as
below.
Scope of D-Register Group Contents Read Write
D0001~D0099 PROCESS
Indication of a basic driving-related
information
X
D0100~D0199 FUNCTION Set up the driving-related Information
D0200~D0299 RESERVATION
Set up the time and reservation
functions
D0300~D0399 IS Set up the inner-signal
D0400~D0499 ALARM Set up the Alarming and Time Signal
D0500~D0599 PID P.I.D Setting
D0700~D0799 COMM
Indication of communication-related
information
X
D0800~D0899 OUTPUT
Set up the Control printing & DO
printing
D0900~D0999 INPUT Set up of input
D1000~D1099 PROGRAM Set up the pattern of Program
Each of D-Register is composed of 4 places of 16 number (2-Byte).
