SAMWONTECH
1st Edition of TEMP880S IM : Sep. 21. 2005 Page 3 / 101
1.2 The exterior inspection and accessories identification
▶ Check the exterior of the product to make sure the product is not damaged when it is first purchased. ▶
▶ Also, check the following matters.
1.2.1 Features of ordered product confirmation
▶ Confirm the obtained product is identical with what you order.
▶ How to confirm: Confirm feature code of label on the right side of the box or left side of the product ▶
▶ case.
Model
Feature
Code
Appendix
Code
UDC Contents
- 1
I/O1 BOARD (10 POINT : basis)
→ 24V SMPS internally equipped
- 2
I/O2 BOARD (10 POINT : addition)
0 RS232C (basis)
1
RS485 (option)
TEMP880S
/UDC UDC100 (option)
☞ In the case of generic model, the code is TEMP880S-10 (I/O 10POINT + RS232C).
1.2.2 Contents confirmation
▶ Confirm the following contents are included.
TEMP880S mainframe Fixed mount Manual
I/O1 BOARD + 30 Pin Cable
→ 24V SMPS included(RELAY driving)
I/O2 BOARD + 14 Pin Cable
→ Included only for TEMP880S-20 or -21
To Next Page
