Samwon Tech TEMP880S User Manual

SAMWONTECH
1st Edition of TEMP880S IM : Sep. 21. 2005 Page 18 / 101
2. INSTRUCTION MANUAL
2.1 SETTING BUTTON
▶ This product is a programmable controller that is set up as touch screen for a user to use easily.
2.1.1 BASIC SETTING BUTTON
▶ Basic control button is as the following table(1-1).
Table 1-1. BASIC SETTING BUTTON
Button Type Button Explanation
1
Upper Main
Bar
Change screen according to left
and right touch.
2
General
Active
Button
For general action or choice.
3
Page
Up/Down
Button
Used for switching pages in the
same screen.
4
Setting
Value
Choice
Button
Used for choosing setting value.
5
Setting
Value
Input
Button
Switch to setting value input
screen.
6
Setting
Value
Change
Button
Used for changing more than
two setting values.
