No. Instruction Contents Additional Explanation
○
1
INNER SIGNAL
Sets relay number to display Inner
Signal.
▶ Refer to 2.12.3 Inner Signal Setting
○
2
TIME SIGNAL
Sets relay number to display Time
Signal.
▶ Refer to 2.10.4 Time Signal Setting
○
3
ALARM SIGNAL
Sets relay number to display Alarm
Signal.
▶ Refer to 2.12.6 Alarm and DI ERROR
▶ Name Setting
▶
○
4
DI SIGNAL
Sets relay number to output DI
Signal.
▶ Refer to 2.12.6 DI ERROR Name
▶ Setting
○
5
DI OUTPUT
Sets output mode of DO(RELAY)
when DI concerned occurs.
▶ FWD
-DI OFF: ”OFF” contact point of
-DI OFF: DO(RELAY)which is set up
-DI ON : ”ON” contact point of
-DI ON : DO(RELAY)which is set up
▶ REV
-DI OFF:”OFF” contact point of
-DI OFF: DO(RELAY)which is set up
-DI ON :”ON” contact point of
-DI ON : DO(RELAY)which is set up
○
6
DI MODE
Sets conversion of operation
condition when DI concerned
occurs.
▶ STOP : Converts RUN => STOP, and
▶ displays DI Error screen.
▶ RUN : Maintains RUN condition, and
▶ displays DI Error screen.
☞ When STOP, RUN simultaneously
▶ occur, STOP > RUN.
○
7
WAIT DAMPER
OFF
Determines whether there is output
of DAMPER OFF during WAIT.
○
8
RUN SIGNAL
Sets relay number to output
Operation (Run) Signal.
▶ Relay is turned on after time you set.
○
9
END SIGNAL
Sets relay number of signal to
output when program operation is
terminated.
▶ Relay is turned on during times set up
▶ when program operation is
▶ terminated.
○
10
High
Temperature
Room
DAMPER ON
Sets relay number of DAMPER ON
signal of high temperature room to
output.
○
11
High
Temperature
Room
DAMPER OFF
Sets relay number of DAMPER OFF
signal of high temperature room to
output.
○
12
Laboratory
DAMPER ON
Sets relay number of DAMPER ON
signal of normal temperature room
to output.
○
13
Laboratory
DAMPER OFF
Sets relay number of DAMPER OFF
signal of normal temperature room
to output.
▶ Used for the exhaustion during
▶ operation of normal sector.
○
14
Low
Temperature
Room
DAMPER ON
Sets relay number of DAMPER ON
signal of low temperature room to
output.
