SAMWONTECH
1st Edition of TEMP880S IM : Sep. 21. 2005 Page 92 / 101
4.4.2 FUNCTION
▶ FUNCTION Group is consist with a D-Register which is related to the motions of TEMP880S.
▶ D-Register related to PROGRAM Driving
D-Reg. Signs Contents
D0100 SET_PTNO Set up the No. of a pattern which is for driving a Program
D0109 DEFROST_CYCLE Set up defrost cycle
D0110 DEFROST_SP Set up defrost temperature
D0111 DEFROST_TIME Set up defrost time
D0112 DEFROST Set up whether to use manual defrost ( 0 : OFF, 1 : ON )
▶ D-Register related to Motions
D-Reg. Signs Driving Contents Setting Value Contents
RUN 1 PROG RUN
HOLD 2 HOLD ON/OFF
STEP 3 SEGMENT STEP
D0101 MODE
STOP 4 PROG STOP
STOP 0 Set up the STOP MODE
COLD 1 Set up the COLD MODE
D0105 PWRMODE
HOT 2 Set up the HOT MODE
