PY Manual Copyright © 2006 SANYO DENKI AMERICA, Inc.
94
Internal Velocity Command Value #2
VCI2
Remote Operator Mode:
1
Page:
9
Default Value:
1000 min
-1
Function: Setting Range:
0 to 32767 min
-1
Description:
• Set a velocity command value.
•
It is enabled by setting the Func3 parameter bits 3, 2, 1, and 0 to “1010” respectively, and turning the CN1-35
pin “ON” and the CN1-36 pin “OFF”.
•
The drive must be configured for velocity mode operation.
Internal Velocity Command Value #3 VCI3
Remote Operator Mode:
1
Page:
10
Default Value:
1500 min
-1
Function: Setting Range:
0 to 32767 min
-1
Description:
• Sets a velocity command value.
•
It is enabled by setting the Func3 parameter bits 3, 2, 1, and 0 to “1010” respectively, and simultaneously turning
both the CN1-35 pin and the CN1-36 pins “ON”.
• The drive must be configured for velocity mode operation.
Current Limit, Internal Value IILM
Remote Operator Mode:
1
Page:
11
Default Value:
100 %
Function:
Current Limit
Setting Range:
30 to (IP/IR) x 100
Description:
• By setting Func1, Bit 0 to “0” and turning “ON” pin ILM (CN1-31 pin), the current is clamped at the above set
value. However, it is impossible to set the value higher than the IP value.
•
This parameter can be set within the range from 30% to (IP/IR x 100)%.
IP: Peak armature current.
IR: Rated armature current.
