Sanyo PLC-WL2500 User Manual

11
HDMI
ASPECT
Part Names and Functions
Note:
Toensuresafeoperation,pleaseobserve
thefollowingprecautions:
–Donotbend,drop,orexposethe
remotecontroltomoistureorheat.
–Forcleaning,useasoftdrycloth.Do
notapplybenzene,thinner,spray,or
anychemicalmaterial.
Remote Control
⑦
⑩
④
②
⑧
⑨
⑤
⑥
⑪
⑫
③
② AUTO SET button
ExecutethesettingofAutosetup
(includesInputsearchfunctionand
AutoPCadj.function).(pp.23,45)
⑤ S-VIDEO button
SelecttheS-VIDEOinputsource.(p.37)
⑥ Point ▲▼◄►
buttons
–SelectanitemoradjustthevalueintheOn-ScreenMenu.
(p.21)
–PantheimageintheDigitalzoom+/-mode.(p.36)
⑬
MUTE button
Mutethesound.(p.24)
⑦ SCREEN button
Selectascreenmode.(pp.26,35-36,43)
⑰ P-TIMER button
OperatetheP-timerfunction.(pp.26,52)
⑩ NO SHOW button
Temporarilyturnofftheimageonthescreen.(p.26)
⑯ LAMP button
Selectalampmode.(pp.25,54)
⑲ KEYSTONE button
Correctthekeystonedistortion.(pp.23,46)
⑳ SELECT button
–Executetheselecteditem.(p.21)
–ExpandorcompresstheimageinDigitalzoommode.(p.36)
⑧ MENU button
OpenorclosetheOn-ScreenMenu.(p.21)
⑨ FREEZE button
Freezethepictureonthescreen.(p.25)
⑫ VOLUME +/- buttons
Adjustthevolumelevel.(p.24)
① ON/STAND-BY button
Turntheprojectoronoroff.
(pp.18-20)
③ COMPUTER 1/2 buttons
SelecttheCOMPUTER1or
COMPUTER2inputsource.
(pp.27-28,38)
⑪ D.ZOOM ▲▼ buttons
Zoominandouttheimages.(pp.25,36)
⑭ IMAGE button
Selecttheimagemode.(pp.26,33,40)
㉑ COMPONENT button
SelecttheCOMPONENTinputsource.(p.38)
④ VIDEO button
SelecttheVIDEOinputsource.(p.37)
⑱ INFO. button
Operatetheinformationfunction.(pp.25,59)
①
⑮
㉑
⑲
⑬
⑯
⑳
⑭
⑱
㉒
⑰
⑮ ASPECT button
Selectascreenaspectfrom4:3,16:9 and 16:10.(pp.25,50)
㉒ HDMI button
SelecttheHDMIinputsource.(p.38)
