16
Installation
Connecting to Component Video Equipment
Unplugthepowercordsof
boththeprojectorandexternal
equipmentfromtheACoutlet
beforeconnectingcables.
Cables used for connection
•Audiocables
•Scart-VGAcable
•Componentcable
•Component-VGAcable
•HDMIcable
(Cablesarenotsuppliedwiththisprojector.)
ExternalAudioEquipment
COMPUTERIN/
COMPONENTAUDIOIN
Audiocable
(stereo)
Audiocable
(stereo)
AudioInput
ComponentVideoOutput
(Y,Pb/Cb,Pr/Cr)
RGBScart21-
pinOutput
AudioOutput
Scart-VGA
cable
Component-
VGAcable
AUDIOOUT
(stereo)
Component
cable
COMPUTERIN1/COMPONENTIN
HDMI
HDMIOutput
HDMI
cable
