Part Names and Functions
① Lamp Cover
② Top controls
③ Adjustable feet
④ Infrared Remote Receiver
⑤ Projection Lens
⑥ Speaker
⑦ Lens Cover
⑧ Exhaust vent
⑨ LAN Connection Terminal
⑩ Indicators
⑪ Focus Ring
⑫ Power Cord Connector
⑬ Filter
⑭ Security Bar
⑮ Terminals and Connectors

Note:
⑨
LANConnectionTerminalisfortheNetwork
function.Refertotheowner’smanualof“Network
Set-upandOperation”.
 Kensington Security Slot
ThisslotisforaKensingtonlockusedtodeter
theftoftheprojector.
*KensingtonisaregisteredtrademarkofACCO
BrandsCorporation.
Front
⑤
Side
⑬
⑨

⑪⑩ ⑫
①
④
⑮
⑭
②
⑦
③
③
⑥
CAUTION
Donotturnonaprojectorwithlenscoverattached.High
temperaturefromlightbeammaydamagelenscover
andresultinfirehazard.
⑧
CAUTION
Hotairisexhaustedfromtheexhaustvent.Donotput
heat-sensitiveobjectsnearthisside.
