-18-
Optical Parts Disassembly
Polarized glass
Polarized glass-in Ass'y
(M2.5x5)x1
Film sheet
c Polarized glass-in disassembly
Fig.3
* Mount the polarized
glass as the film at-
tached side faces the
prism side.
Hooks
