Positioning the Projector
Forprojectorpositioning,seethefiguresbelow.Theprojectorshouldbesetperpendicularlytotheplaneofthe
screen.
Installation
Note:
 •The brightness in the room has a great influence on picture quality. It is recommended to limit ambient
lightinginordertoobtainthebestimage.
 •Allmeasurementsareapproximateandmayvaryfromtheactualsizes.
Adjustable Foot
AdjustableFoot
FootLockLatch
Projectionanglecanbeadjustedupto10.0degreeswith
theadjustablefoot.
Liftthefrontoftheprojectorandpushthefootlock
latchontheprojector.
Releasethefootlocklatchtolocktheadjustablefoot
androtatetheadjustablefoottoadjustthepositionand
tilt.
Toretracttheadjustablefoot,liftthefrontofthe
projectorandpushandundothefootlocklatch.
Keystonedistortionoftheprojectedimagecanbe
correctedbymenuoperation.(seepages23,44-45)
A
B
100"
150"
200"
250
167
125
83
300"(wide)
40"
300"(tele )
38.7'(11.80m)
32.3'(9.84m)
21.5'(6.55m)
16.1'(4.90m)
Max. Zoom Min. Zoom
A
: B = 6 : 1
(Inch Diagonal)
10.7'(3.26m)
(Center)
4.3'(1.30m)
Screen Size
(W x H) mm
4 : 3 aspect ratio
40”
Zoom (max)
813 x 610
4.3'(1.30m)
100”
2032 x 1524
10.7'(3.26m)
150”
3048 x 2286
16.1'(4.90m)
200”
4064 x 3048
21.5'(6.55m)
300”
6096 x 4572
32.3'(9.84m)
Zoom (min)
5.1'(1.55m) 12.9'(3.92m) 19.4'(5.90m) 25.8(7.87m)38.7'(11.80m)
