Installation
Connecting to Component Video and RGB ( Scart) Equipment
Note:
 •WhentheAUDIOOUTisplugged-in,theprojector'sbuilt-inspeakerisnotavailable.
 •Seepage72fororderingoptionalcables.
Cables used for connection
•AudioCables(MiniPlug:stereo)
•Scart-VGACable
•ComponentCable
•Component-VGACable
(Cablesarenotsuppliedwiththisprojector.)
ExternalAudioEquipment
AUDIOIN
Audiocable
(stereo)
Audiocable
(stereo)
AudioInput
ComponentVideoOutput
(Y,Pb/Cb,Pr/Cr)
AudioOutput
RGBScart
21-pinOutput
Scart-VGA
cable
Component-
VGAcable
AUDIO OUT
(stereo)
Component
cable
COMPUTERIN1/S-VIDEOIN/COMPONENTIN
UnplugthepowercordsofboththeprojectorandexternalequipmentfromtheACoutletbeforeconnecting
cables.
