Sanyo PLC-XE33

74
Appendix
COMPUTER IN 1 /COMPONENT IN /MONITOR OUT (ANALOG)
Terminal: Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
Configurations of Terminals
Red/Cr/S-CInput/Output 
Ground(Horiz.sync.)
Green/Y/S-YInput/Output
-----
Blue/Cb/---Input/Output
Ground(Red)
Ground(Green)
Ground(Blue)
1
5
2
4
3
6
7
8
+5VPower/-----
Horiz.sync.Input/Output(CompositeH/Vsync.)
Ground(Vert.sync.)
DDCData
/-----
Ground/-----
Vert.sync.
DDCClock
/-----
9
13
10
12
11
14
15
RX–
TX+
TX–
RX+
2
3
4
5
6
7
8
1
LAN TERMINAL
-----
-----
----------
