Sanyo PLC-XE33

33
Computer Input
Image Adjust Menu
Image Adjustment
Reset
PresstheMENUbuttontodisplaytheOn-Screen
Menu.UsethePoint▲▼buttonstoselectImage
adjustandthenpressthePoint►ortheSELECT
button.
1
2
UsethePoint▲▼buttonsselectthedesireditem
andthenpresstheSELECTbuttontodisplaythe
adjustmentdialogbox.UsethePoint◄►buttonsto
adjustthesettingvalue.
Note:
•WhenWhitebalance Red,GreenorBlueis
adjusted,Color temp.willchangetoUser.
•WhenBlackboard(Green)orColorboard
isselectedinImageselect,Color temp.will
changetoBlackboardorColorboard.
PressthePoint◄buttontodecreasethecontrast;pressthe
Point►buttontoincreasethecontrast(from0to63).
PressthePoint◄buttontodecreasethebrightness;press
thePoint►buttontoincreasethebrightness(from0to63).
Contrast
Brightness
PressthePoint◄buttontolightenredtone;pressthePoint
►buttontodeepenredtone(from0to63).
White balance (Red)
Press the Point ◄ button to lighten green tone; press the
Point►buttontodeepengreentone(from0to63).
White balance (Green)
PressthePoint◄buttontolightenbluetone;pressthe
Point►buttontodeepenbluetone(from0to63).
White balance (Blue)
UsethePoint◄►buttonstoselectthedesiredColortemp.
level(XLow,Low,Mid,orHigh).
Color temp.
Use the Point ◄► buttons to adjust the gamma value to
obtainabetterbalanceofcontrast(from0to15).
Gamma
PressthePoint◄buttontodecreasethesharpnessofthe
image;pressthePoint►buttontoincreasethesharpness
oftheimage(from0to15).
Sharpness
To reset the adjusted data, select Reset and press the
SELECTbutton.Aconfirmationboxappearsandthenselect
Yes.Alladjustmentswillreturntotheirpreviousfigures.
UsethePoint◄►
buttonstoadjustthe
settingvalue.
SelectedImagemode
