Operating the Scale
103
Data output example: + 1255.7 g
Position 1 2 3 4 5 678910111213141516
+***1255. 7*g**CRLF
Position 1: Plus or minus sign or space
Position 2: Space
Position 3–10: Weight with a decimal point; leading zeros = space
Position 11: Space
Position 12–14: Unit symbol or space
Position 15: Carriage return
Position 16: Line feed
Data Output With ID Code
When data with an ID code is output, the ID code consisting of 6 characters
precedes the data with the 16-character format. These 6 characters identify
the subsequent value.
12345678910111213141516171819202122
IIIIII+*DDDDDDDD*UUUCRLF
*****– . . ...... ***
* ********
000000
I: ID code character
1)
U: Unit symbol
1)
see “Toggling
*: Space between Weight Units”
D: Digit or letter CR: Carriage return
LF: Line feed
1)
depends on scale type; e.g., not all units and characters are
available on scales verified for use in legal metrology
Special Codes
12345678910111213141516171819202122
S t a t ********––******CRLF
HH
LL
C
*: Space L: Underload
– –: Weight L L: Underload
H: Overload in checkweighing
H H: Overload in checkweighing C: Calibration/adjustment
Error Codes
12345678910111213141516171819202122
S t a t *****E r r *###****CRLF
*: Space # # #: Error code number
ID code characters I
1)
Stat Status
ID Identifier
L ID Weighing series no.
W ID Weight set number
Nom. Exact calibration weight
S ID Sample ID
NUM Numeric input
T1 Application tare
memory 1
N Net weight (T1 = 0)
N1 Net weight (T1# 0)
Qnt Quantity
Prc Percentage
nRef Reference sample
quantity
pRef Reference percentage
wRef Average piece weight
Wxx% Reference percentage
weight
mDef Target value for animal
weighing
Mul Multiplication factor for
animal weighing
x-Net Result in animal weighing
x-Res Calculated result in
animal weighing
Res Result using equation
(Calculation)
Setp Target value for
checkweighing
Min Lower limit for
checkweighing
Max Upper limit for
checkweighing
Time Time that a value
was stored
Compxx No. of components
in formulation
Tot.cp Total weight
in formulation
n Transaction counter
Total Sum of all values
Avg Average in statistics
s Standard deviation
srel Variation coefficient
Diff Difference between
maximum and minimum
