104
Data Input Format
You can connect a computer to your scale to send commands via the scale
interface port to control scale functions and applications.
The commands sent are control commands and may have different formats;
e.g., control commands can have up to 26 characters. Each character must
be transmitted according to the settings configured in the Setup menu for
data transmission.
Format for Control Commands
Format 1: Esc ! CR LF
Format 2: Esc ! # _ CR LF
Format 3: Esc ! # & (max. 20 &) & _ CR LF
Format 4: Esc ! # & (max. 8 &) & _ CR LF
Esc: Escape _: Underline (ASCII: 95)
!: Command character CR: Carriage RETURN (optional)
#: Number LF: Line FEED (optional)
&: Number or letter max: depends on
command character:
See “Overview” i.e. parameter:
for an ASCII table once the max. length is
reached, input received is
cut off, rather than
discarded as with keyboard
input
Format 1
! Meaning
I Weighing mode 1
L Weighing mode 2
M Weighing mode 3
N Weighing mode 4
O Block keys
P Print
R Unblock keys
S Restart
T Tare and zero
Z Internal calibration/adjustment
Format 2
!# Meaning
f3 Zero
f4 Tare (without zeroing)
kF1 Soft key 1* Function depends
... on setting in applic-
kF6 Soft key 6* ation program
kF7 Function key M
kF8 Function key D
s3 Function key c
x0 Perform internal calibration
x1 Print scale model
x2 Print weighing cell
serial number
x3 Print weighing cell
software version
x4 Print display and control unit
software version
x5 Print (GMP) scale ID number
x6 Print weight set (“inventory”)
number
x7 Print weighing series number
Format 3 (not allowed
in the Setup menu)
!# Meaning
z5 Input (GMP) scale ID number
z6 Input weight set (“inventory”)
number
z7 Input weighing series number
Format 4
! Meaning
t Text input in display
* numbered from right to left
