Operating the Scale
63
Practical Example
Checkweighing samples of 170 g, with an allowable tolerance of –5 g and +10 g. Printout of upper and lower tolerance
limits. Weighed values are printed out automatically when stability is reached and weight value is within the control range.
Settings (changes in the factory settings required for this example):
Setup: App: Application 2: Checkweighing: Automatic printout of OK values: Yes
Step Key (or instruction) Display/Output
1. Turn on the scale and configure e/[ON/OFF]
the settings as indicated above
2. Delete previous setting if necessary c
3. Prepare a container Place empty container
for the samples on the scale
4. Tare the scale t
5. Enter initialization values Param. soft key
6. Enter target value via the Place ideal sample
scale (here: 170 g) in container
7. Store target value and l soft key
unload scale Remove ideal sample
from scale
8. Enter value for lower limit 1 6 5
(170 g – 5 g) and store l soft key
