Satec System 295 User Manual

Communications Operation 107
The following illustration shows the printout format: * MM/DD/YY HH:MM:SS
1 2 3 4 5 6 7 8 9
V1
4
Chars
V2
4
Chars
V3
4
Chars
A1
5
Chars
A2
5
Chars
A3
5
Chars
KW
6
Chars
PF
4
Chars
+KWH
6
Chars
10 11 12 13 14 15 16 17 18
-kWH
6
Chars
FREQ
4
Chars
BRK
2
Chars
KVAR
6
Chars
KVARH
6
Chars
KVA
6
Chars
MAX_DM
6
Chars
A_MD1
5
Chars
A_MD2
5
Chars
19 20 21 22 23 24 25 26 27
A_MD3
5
Chars
I_UB
4
Chars
APP_MD
6
Chars
THD_U1
4
Chars
THD_ U2
4
Chars
THD_U3
4
Chars
THD_I1
4
Chars
THD_I2
4
Chars
THD_I3
4
Chars
Measured quantities represented in the print report are listed in Table 5.1.
Table 5.1 Printout Format
Field
number
Parameter Description Offset in the
string
1, 2, 3 V1, V2, V3 Voltage per phase 9, 17, 25
4, 5, 6 A1, A2, A3 Current per phase 33, 41, 49
7 kW kW total 56
8 PF Total power factor 66
9 +kWH kWh imported 72
10 -kWH kWh exported 87
11 FREQ Frequency 97
12 BRK Status inputs (breaker status) 107
13 kVAR kvar total 112
14 kVARH kvarh net 120
15 kVA kVA total 128
16 MAX_DM Maximum kW demand 136
17,18,19 A_MD 1,2,3 Maximum ampere demand per phase 145,153,168
20 I_UB Neutral current 170
21 APP_MD Maximum kVA demand 183
22 THD_U1 %THD voltage L1/L12 194
23 THD_U2 %THD voltage L2/L23 202
24 THD_U3 %THD voltage L3 210
25 THD_I1 %THD current L1 218
26 THD_I2 %THD current L2 226
27 THD_I3 %THD current L3 234
