Operating The PM295 35
3.3.3 Menu Map
Figure 3-2 shows a map illustrating the PM295 menus. Setup groups are accessed
via 13 primary menus that are selected by main menu entries. For setup groups, a
map shows the abbreviated labels of menu entries accented with boldface. Primary
menus can have enclosed secondary menus and sub-menus. Menu dependent
information is provided in this manual for each setup group individually.
To enter the main menu, you should select an access mode that specifies an
authorization level for setup operation. Entering the view level allows you to inspect
all setups, but does not permit changes in setup configuration. To change setup
parameters, you should enter the main menu at the protected level. If password
protection is enabled, you will be prompted to enter a password.
3.3.4 Entering/Quitting Programming Mode
To enter programming mode from operational mode:
Ä Press SELECT.
The first menu you enter from operational mode provides a selection of the
ACCESS LEVEL for setup operation. The menu has three entries indicated by
labeled button-windows, as shown in the following illustration. The SEE entry lets
you pass into the view level, allowing to inspect the present setup configuration. The
CHG entry lets you pass into the protected level allowing the changing of
programmable setups and the performing of management procedures.
SEE
CHG
ESC
To enter the view level:
Ä Press SELECT to choose the SEE window.
Ä Press ENTER.
To enter the protected level:
Ä Press SELECT to choose the CHG window.
Ä Press ENTER.
To quit programming mode and return to operational mode:
Ä Press SELECT to choose the ESC window.
Ä Press ENTER.
