3.3.13 Pulsing Relay Setup
Select the PulS entry from the MAIN menu and press ENTER.
The PULSING RELAY SETUP menu consists of 4 sub-menus, each meant for one
of 4 relay outputs. The upper window lists sub-menus for relay outputs, the central
window lists available outputs for the selected relay, and the lower window displays
the pulsing value in units per hour for the energy pulsing parameter. Available
outputs for pulse relay are listed in Table B-5 (see Appendix B) with the
corresponding window labels. See Section 4.9 for information on relay output
operation.
rEL.1
0
Ac.Ei
To select a relay output setup:
Ä From the upper window, select the desired relay with the
up/down arrow keys.
To change the output parameter for the relay:
Ä Press SELECT to choose the central window.
Ä Scroll through the list of outputs with the up/down arrow
keys until the desirable output label appears.
To change the number of unit-hours for energy pulses:
Ä Press SELECT to choose the lower window.
Ä Adjust the amount of unit-hours per pulse with the up/down arrow keys. The
available range is 1-9999.
To enter the changes made into setup:
Ä Press ENTER to return to the upper window.
To quit the menu:
Ä From the upper window, press ENTER to return to the MAIN menu.
TROUBLESHOOTING
If your setup for the energy pulse output is not accepted by the instrument, check
whether you specified the amount of unit-hours per pulse.
