Appendix B Programmable Parameters
Appendix B Programmable Parameters
Table B-1 Setup Parameters
Access
Parameter Description Options Front
panel
Commu-
nications
Basic setup
• •
See Table B-2
Communications setup
•
See Table B-3
Discrete input setup
• •
Allocation group Selects one of the four input
groups
Status inputs
Pulse inputs
Analog output
selector inputs
External sync
pulse input
Allocation mask Defines the inputs to be allocated
to the group
Binary mask
0000000 to
1111111
Counter setup
• •
Counter number Selects one of the eight pulse
counters
1 to 8
Discrete input
number
Connects one of the eight discrete
(pulse) inputs to the counter
1 to 8
Scale factor Defines the number of units per
pulse
1 to 9999
Analog output setup
• •
Analog channel
number
Selects one of the sixteen
multiplexed analog channels
1 to 16
Output parameter
group
Specifies the group for the output
parameter
see Table B-4a
Output parameter Specifies the measurement
parameter for the channel
see Table B-4b
Low (zero) scale Specifies a zero-scale (0/4 mA)
reading
see Table B-4b
High (full) scale Specifies a full-scale (20 mA)
reading
see Table B-4b
Analog expander setup
• •
