Page #133 background image
Appendix B Programmable Parameters 125
Table B-1 Setup Parameters
Access
Parameter Description Options Front
panel
Commu-
nications
Analog channel
number
Selects one of the 14 analog
channels
1 to 14
Output parameter
group
Specifies the group for the output
parameter
see Table B-4a
Output parameter Specifies the measurement
parameter for the channel
see Table B-4b
Low (zero) scale Specifies a zero-scale (0/4 mA)
reading
see Table B-4b
High (full) scale Specifies a full-scale (20 mA)
reading
see Table B-4b
Pulsing relay setup
Relay output
number
Selects one of the four relay
outputs
1 to 4
Output parameter Specifies pulsing parameter see Table B-5
Unit-hours per
pulse
Defines the number of unit-hours
per pulse for energy pulses
0, 1 to 9999
Event/alarm setpoints
Setpoint number Selects one of the sixteen
setpoints
1 to 16
Trigger conditions definition
Condition number Selects one of the four setpoint
conditions
1 to 4
Conjunction Specifies the logical operation for
the condition
OR/AND
Trigger group Specifies the group for the trigger
parameter
see Table B-6
Trigger parameter Specifies the trigger parameter see Table B-7
Operate condition Specifies the test condition for
the trigger
see Table B-8
Operate limit Specifies the operate limit value
for a numeric trigger
see Table B-7
Release limit Specifies the release limit value
for a numeric trigger
see Table B-7
Setpoint actions definition
