Operating The PM295 39
3.3.8 Serial Port Setup
Select the Port entry from the MAIN menu and press ENTER.
Serial port setup specifies communications parameters that the PM295 needs to
communicate with a master computer or a printer. The SERIAL PORT SETUP
menu operates the same as the BASIC SETUP menu (see above). Table B-3 in
Appendix B lists all communications parameters with the corresponding labels and
applicable choices. For more information on communications operation, refer to
Chapter 5.
Port
Prot
ASCII
To select and view a setup parameter:
Ä From the central window, scroll through parameters with
the up/down arrow keys until the label of the desired
parameter appears. The parameter value will be indicated in
the lower window.
To change the setup parameter :
Ä Press SELECT to choose the lower window.
Ä Scroll through applicable values with the up/down arrow keys until the desired
value appears.
Ä Press ENTER to return to the central window.
To quit the menu:
Ä From the central window, press ENTER to return to the MAIN menu.
3.3.9 Discrete Input Setup
Select the dinP entry from the MAIN menu and press ENTER.
The DISCRETE INPUT SETUP menu consists of four sub-menus, as shown in the
following illustrations:
S.InP
1.1.1.1.
1.0.0.0.
Status
inputs
P.InP
0.0.0.0.
0.0.1.1.
Pulse
inputs
0.0.0.0.
0.0.0.1.
An.SL
Analog
output
selector
E.Snc
0.0.0.0.
0.0.0.1.
External
synchro-
nization
pulse
input
