Appendix A Display Formats 123
Table A-1 Displayed Parameters
Page/
sub-page
Window Range,
digits
Parameter À Unit Á
5/2 6 4 Status input #6 (0/1)
5/2 8 5 Status input #7 (0/1)
5/2 9 5 Status input #8 (0/1)
5/3 1 3 Relay #1 status (0/1)
5/3 2 3 Relay #2 status (0/1)
5/3 3 3 Relay #3 status (0/1)
5/3 4 4 Relay #4 status (0/1)
5/4 1 3 Phase L1 angle degrees
5/4 2 3 Phase L2 angle degrees
5/4 3 3 Phase L3 angle degrees
6/1-8 3, 6, 9 9 Counter #1-#8
NOTES
À Display readings for all electrical quantities except demands and real-time harmonic parameters (pages
2 and 4) are sliding average values.
Á Voltage and current readings with a decimal point are displayed in kV, kA. Auxiliary current readings
with a decimal point are displayed in amperes. Power readings with a decimal point are displayed in
MW, Mvar, MVA. The short range energy readings (page 3) with a decimal point are displayed in MWh,
Mvarh, MVAh. When the value width is over the window resolution, the right-most digits of the reading
will be truncated.
 The maximum range for short energy readings displayed on page 3 is 9,999 MWh/Mvarh/MVAh.
Beyond this value the reading rolls over to zero, and the corresponding display window will flash until the
user presses any key.
à Date format can be customized.
