Appendix A Display Formats
Table A-1 Displayed Parameters
Page/
sub-page
Window Range,
digits
Parameter À Unit Á
3/8 3, 6, 9 9 kvarh total (up to 999,999,999) kvarh
3/9 3, 6, 9 9 kVAh total (up to 999,999,999) kVAh
3/10 2, 5 6 Date of the last energy reset Ã
3/10 3, 6 6 Time of the last energy reset
4 1 3 H01 harmonic voltage L1/L12 V/kV
4 2 3 H01 harmonic voltage L2/L23 V/kV
4 3 3 H01 harmonic voltage L3 V/kV
4 4 4 H01 harmonic current L1 A/kA
4 5 4 H01 harmonic current L2 A/kA
4 6 4 H01 harmonic current L3 A/kA
4 7 3 H01 harmonic total power factor
4 8 5 H01 harmonic total kW kW/MW
4 9 5 H01 harmonic total kvar kvar/Mvar
4/1-19 1 3 H03-H39 harmonic voltage L1/L12 V/kV
4/1-19 2 3 H03-H39 harmonic voltage L2/L23 V/kV
4/1-19 3 3 H03-H39 harmonic voltage L3 V/kV
4/1-19 4 4 H03-H39 harmonic current L1 A/kA
4/1-19 5 4 H03-H39 harmonic current L2 A/kA
4/1-19 6 4 H03-H39 harmonic current L3 A/kA
4/1-19 7 3 H03-H39 harmonic total PF
4/1-19 8 5 H03-H39 harmonic total kW kW/MW
4/1-19 9 5 H03-H39 harmonic total kvar kvar/Mvar
5 4 4 K-Factor L1
5 5 4 K-Factor L2
5 6 4 K-Factor L3
5/1 1 3 Voltage unbalance %
5/1 2 3 Current unbalance %
5/1 3 3 Phase rotation (POS/NEG/ERR)
5/1 7 3 Auxiliary current mA/A
5/2 1 3 Status input #1 (0/1)
5/2 2 3 Status input #2 (0/1)
5/2 3 3 Status input #3 (0/1)
5/2 4 4 Status input #4 (0/1)
5/2 5 4 Status input #5 (0/1)
