Appendix A Display Formats 121
Table A-1 Displayed Parameters
Page/
sub-page
Window Range,
digits
Parameter À Unit Á
2 7 3 Frequency Hz
2 8 5 Max. block interval kW demand kW/MW
2 9 5 Max. block interval kvar demand kvar/Mvar
2 10 4 Max. block interval kVA demand kVA/MVA
2/1 8 5 Max. sliding window kW demand kW/MW
2/1 9 5 Max. sliding window kvar demand kvar/Mvar
2/1 10 4 Max. sliding window kVA demand kVA/MVA
2/2 8 5 Maximum thermal kW demand kW/MW
2/2 9 5 Maximum thermal kvar demand kvar/Mvar
2/2 10 4 Maximum thermal kVA demand kVA/MVA
2/3 8 5 Predicted sliding win. kW demand kW/MW
2/3 9 5 Predicted sliding win. kvar demand kvar/Mvar
2/3 10 4 Predicted sliding win. kVA demand kVA/MVA
2/4 8 5 Accumulated kW demand kW/MW
2/4 9 5 Accumulated kvar demand kvar/Mvar
2/4 10 4 Accumulated kVA demand kVA/MVA
3 1 3 Voltage THD L1/L12 %
3 2 3 Voltage THD L2/L23 %
3 3 3 Voltage THD L3 %
3 4 4 Current THD L1 %
3 5 4 Current THD L2 %
3 6 4 Current THD L3 %
3 7 3 Neutral current A/kA
3 8 5 kWh import (up to 9,999 MWh) Â kWh/MWh
3 9 5
kvarh net (up to ±9,999 Mvarh) Â
kvarh/Mvarh
3 10 4 kVAh (up to 9,999 MVAh) Â kVAh/MVAh
3/1 3, 6, 9 9 kWh import (up to 999,999,999) kWh
3/2 3, 6, 9 9 kWh export (up to -999,999,999) kWh
3/3 3, 6, 9 9
kWh net (up to ±999,999,999)
kWh
3/4 3, 6, 9 9 kWh total (up to 999,999,999) kWh
3/5 3, 6, 9 9 kvarh import (up to 999,999,999) kvarh
3/6 3, 6, 9 9 kvarh export (up to -999,999,999) kvarh
3/7 3, 6, 9 9
kvarh net (up to ±999,999,999
kvarh
