120
Appendix A Display Formats
Table A-1 Displayed Parameters
Page/
sub-page
Window Range,
digits
Parameter À Unit Á
1 1 3 Voltage L1/L12 V/kV
1 2 3 Voltage L2/L23 V/kV
1 3 3 Voltage L3/L31 V/kV
1 4 4 Current L1 A/kA
1 5 4 Current L2 A/kA
1 6 4 Current L3 A/kA
1 7 3 Total power factor
1 8 5 Total kW kW/MW
1 9 5 Total kvar kvar/Mvar
1 10 4 Total kVA kVA/MVA
1/1 1 3 Voltage L1 V/kV
1/1 4 4 Current L1 A/kA
1/1 7 3 Power factor L1
1/1 8 5 kW L1 kW/MW
1/1 9 5 kvar L1 kvar/Mvar
1/1 10 4 kVA L1 kVA/MVA
1/2 2 3 Voltage L2/L23 V/kV
1/2 5 4 Current L2 A/kA
1/2 7 3 Power factor L2
1/2 8 5 kW L2 kW/MW
1/2 9 5 kvar L2 kvar/Mvar
1/2 10 4 kVA L2 kVA/MVA
1/3 3 3 Voltage L3/L31 V/kV
1/3 6 4 Current L3 A/kA
1/3 7 3 Power factor L3
1/3 8 5 kW L3 kW/MW
1/3 9 5 kvar L3 kvar/Mvar
1/3 10 4 kVA L3 kVA/MVA
2 1 3 Maximum volt demand L1/L12 V/kV
2 2 3 Maximum volt demand L2/L23 V/kV
2 3 3 Maximum volt demand L3/L31 V/kV
2 4 4 Maximum ampere demand L1 A/kA
2 5 4 Maximum ampere demand L2 A/kA
2 6 4 Maximum ampere demand L3 A/kA
