To quit the RTC menu:
Ä From the upper window, press ENTER to return to the MAIN menu.
Time Indication
The time is displayed in the order of HH.MM.SS, where the hour and minute are
shown in the central window, and seconds - in the lower window. The user can set
hour and minute independently, and reset seconds to zero.
hour
HH.MM
SS
To update the hour or minute:
Ä Press SELECT to choose the desired item. The hour and
minute indications are now frozen allowing you to adjust
them. The seconds are still being updated.
Ä Adjust the hour or minute indication with the up/down
arrow keys.
Ä Press ENTER to return to the upper window.
To reset seconds:
Ä Press SELECT to choose the second's window.
Ä Press ENTER to return to the upper window.
Date Indication
The date is displayed in the user selected way, for instance, as YY.MM.DD,
MM.DD.YY, or DD.MM.YY, where the first two items are shown in the central
window, and the last - in the lower window. For instructions on setting the date
format, see the next Section 3.3.17. The user can set each item independently.
dAtE
YY
DD.MM.
To update the date:
Ä Press SELECT to choose the desired item.
Ä Set the item using the up/down arrow keys.
Ä Press ENTER to return to the upper window.
Day of Week Indication
The day of week is displayed in the lower window as follows:
Sun Sunday
To Next Page
